BUILT – 1974 IN NORWAY
CONVERTED IN 1991 ACC. TO SOLAS 1974 AMEND
GRT/NRT – 8739/2621
DWT – 1907 AT 3.97 METERS
LOA – 130.25 METERS
BEAM – 18.90 METERS
M/E – 4 X WARTSILA 12V25 OF 2.200 KW EACH. (NEW INSTALLED, AND RUNNING HOURS 800 EACH)
SERVICE SPEED – 19 KNOTS (ABOUT)
REDUCTION GEAR – 2 X LOBMANN AND STOLTERFRONT TYPE
NAVILUS GVA 1120C – REDUCTION 825/300 RPM
AUXILLIARY ENGINES – 5 X VOLVO PENTA TAMD 120 AK – 120 KW EACH
STEERING GEAR – 2 X FRYDENSO HYDRAPILOT
CONSUMPTION – AT 17 KNOTS 1.5 TONS/HOUR IFO 60 CST (+3 MT MGO/DAY)
EMERGENCY GENERATOR – YES
THRUSTERS – YES
OIL WATER SEPARATOR – YES
TOTAL GARAGE CAPACITY – 53 TRUCKS OF 15 METERS EACH, AND 60 PRIVATE CARS IN LOWER HOLD (TANK TOP)
ACCOMODATION – PROVIDED FOR 240 ADDITIONAL PASSENGERS ( 62 CABINS , 215 BERTHS )
UPPER GARAGE – (OPEN AREA) 1312 SQUARE METERS
MAIN GARAGE – (CLOSE AREA) 1567 SQUARE METERS
LOWER GARAGE – (CLOSE AREA)
- HOLD NO. 1 : 182 SQUARE METERS
- HOLD NO. 2 : 238 SQUARE METERS
- HOLD NO. 3 : 340 SQUARE METERS
LOWER GARAGE HEIGHT: 2.4 METERS
MAIN GARAGE HEIGHT: 4.6 METERS
UPPER GARAGE IS OPEN AREA. | |
